12MP FA Lens HK1620MP12 16mm Low distortion Lens 1-inch F2.0 C-Mount

FH至尊

12MP FA Lens HK1620MP12 16mm Low distortion Lens 1-inch F2.0 C-Mount: 1″ C-Mount f=16mm F2.0; High resolution,wavelength 420-1000nm; high contrast,Can suppress stray light; Low distortion 0.3% or less; Locking set screws for focus and Iris; compact appearance for device integration

Tel:+86 020-38312466

Specifications Dimension PDF download Other

Model		HK1620MP12
Image Size		1-inch
Focal length		16mm
F?No.		F2.0-22
M.O.D(m)		0.1-Inf.
Operation	Iris	Manual
	Focus	Manual
Horizontal Angle of View	1" Type	54.0°×43.9°×33.5°
	1/2"Type	28.2°×22.6°×16.9°
	1/3"Type	21.2°×17.0°×12.9°
Distortion		-0.3%
Back?focal?length		11.20mm
Mount		C-Mount
1"FOV		89.3mm×66.3mm(WD=100mm)
Dimension		Ф36.4x45.9mm
Weight		112.0g
Horizontal Resolution		180lp/mm
Filter Thread		M34x 0.5mm
Working Temperature		-20?C ～ +60?C

Product Features
◆ Brand：ZLKC
◆ Image Size：1″ C-mount
◆ Focal length：f=16mm
◆ F No.：F2.0-22
◆ Features：1-inch FA Lens 16mm 12MP Manual Iris Lens, Fixed focus Lens Low distortion C Mount HD Lens

Model
HK1620MP12

Dimension
FH至尊(中国)有限公司官网

Industries Application
These are used in machine vision and ITS monitoring. These cover applications from electronics and semiconductor SMT inspection and robotics to food inspection, postal sorting and inspections of printed images 3C，traffic cameras?and so on
